3T Aluminium Scaffold Towers



Prices on application

Description

A range of industrial grade aluminium scaffold towers are ideal for situations that require both hands and over longer periods of time than would otherwise suit a ladder or step ladder.

This aluminium tower is very easy to install / dismantle.

In line with the Health & Safety Executive (HSE) working at height regulations (2005), we recommend the 3T method of tower erection.

3T stands for ‘Through The Trap Door’ and is an approved method of assembly by the HSE that reduces the risk of the assembler falling. Using this method, the assembler sits on the platform trap-door to add or remove any guard rails above. This system protects the assembler from standing on an unprotected platform. Once guard-rails are secured in position the assembler can climb onto the platform and continue constructing the next level

Product Features:

• Double width scaffold tower
• Heavy-duty spigot for maximum strength
• Crimped abuse resistant joints
• Toe-board and guardrails for additional security
• 3T compliant construction
• 5-year warranty
• Safe Working Load: 250kg; Structure: 750kg
• BSEN1004:2004

Price on application.  Please contact our sales office on 0121 454 7514 x 1 for  pricing.

Specification

.tg {border-collapse:collapse;border-spacing:0;} .tg td{font-family:Arial, sans-serif;font-size:14px;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;} .tg th{font-family:Arial, sans-serif;font-size:14px;font-weight:normal;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;} .tg .tg-s6z2{text-align:center} .tg .tg-baqh{text-align:center;vertical-align:top} .tg .tg-amwm{font-weight:bold;text-align:center;vertical-align:top} .tg .tg-hgcj{font-weight:bold;text-align:center}
Type Approx Working Height Platform
height
Overall
Height
Frame Width Frame Depth Stabiliser
Width
Stabiliser Depth Weight
2735w 3.9m 2.3m 3.6m 2m 0.7m 4.7m 3.5m 105kg
2736w 4.9m 3.3m 4.5m 2m 0.7m 4.7m 3.5m 136kg
2737w 5.8m 4.2m 5.5m 2m 0.7m 4.7m 3.5m 147kg
2738w 6.7m 5.1m 6.4m 2m 0.7m 5.8m 4.6m 156kg
2739w 7.7m 6.1m 7.3m 2m 0.7m 5.8m 4.6m 173kg
2740w 8.6m 7.0m 8.2m 2m 0.7m 5.8m 4.6m 206kg
2741w 9.5m 7.9m 9.2m 2m 0.7m 5.8m 4.6m 215kg
2742w 3.9m 2.3m 3.6m 2m 1.4m 4.7m 4.1m 111kg
2743w 4.9m 3.3m 4.5m 2m 1.4m 4.7m 4.6m 161kg
2744w 5.8m 4.2m 5.5m 2m 1.4m 4.7m 4.6m 176kg
2745w 6.7m 5.1m 6.4m 2m 1.4m 5.8m 5.2m 188kg
2746w 7.7m 6.1m 7.3m 2m 1.4m 5.8m 5.2m 210kg
2747w 8.6m 7.0m 8.2m 2m 1.4m 5.8m 5.2m 248kg
2748w 9.5m 7.9m 9.2m 2m 1.4m 5.8m 5.2m 260kg

Where applicable, approximate working height is calculated as 1,600mm + Last Climbing Height (4th rung from the ladder top) or the Platform Height.
