Description
• Tested to EN 131 standard
• Platform size: 500mm wide x 400mm deep
• Tread size: 500mm wide x 145mm deep
• Available with Expanded Steel, Phenolic or Aluminium Treads
• Colour options: blue, grey or orange
• 2-6 Tread Units: Mobile on 2 rear wheels 150mm dia and 2 front spring loaded castors to achieve weight reactive function. Units move freely when pushed (unmounted) & stand firmly on ground once they are mounted in use
• 7-10 Tread Units: Made mobile on 150mm wheels & the use of a unique grip lift mechanism facilitating movement on 75mm retractable castors
Specification
.tg {border-collapse:collapse;border-spacing:0;}
.tg td{font-family:Arial, sans-serif;font-size:14px;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;border-color:black;}
.tg th{font-family:Arial, sans-serif;font-size:14px;font-weight:normal;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;border-color:black;}
.tg .tg-88nc{font-weight:bold;border-color:inherit;text-align:center}
.tg .tg-v0hj{font-weight:bold;background-color:#efefef;border-color:inherit;text-align:center;vertical-align:top}
.tg .tg-c3ow{border-color:inherit;text-align:center;vertical-align:top}
.tg .tg-uys7{border-color:inherit;text-align:center}
.tg .tg-us36{border-color:inherit;vertical-align:top}
.tg .tg-7btt{font-weight:bold;border-color:inherit;text-align:center;vertical-align:top}
.tg .tg-3xi5{background-color:#ffffff;border-color:inherit;text-align:center;vertical-align:top}
.tg .tg-7g6k{font-weight:bold;background-color:#ffffff;border-color:inherit;text-align:center;vertical-align:top}
.tg .tg-p8bj{font-weight:bold;border-color:inherit;vertical-align:top}
| Treads |
Platform Height |
Overall H x W x D |
Weight |
Tread Type |
| Expanded Steel |
Phenolic |
Aluminium |
| 2 |
460mm |
1460 x 700 x 670mm |
22kg |
9186w |
9195w |
9204w |
| 3 |
690mm |
1690 x 720 x 855mm |
26kg |
9187w |
9196w |
9205w |
| 4 |
920mm |
1920 x 750 x 1055mm |
29kg |
9188w |
9197w |
9206w |
| 5 |
1150mm |
2150 x 840 x 1175mm |
33kg |
9189w |
9198w |
9207w |
| 6 |
1380mm |
2380 x 1030 x 1315mm |
41kg |
9190w |
9199w |
9208w |
| 7 |
1610mm |
2610 x 1160 x 1490mm |
51kg |
9191w |
9200w |
9209w |
| 8 |
1840mm |
2840 x 1160 x 1630mm |
63kg |
9192w |
9201w |
9210w |
| 9 |
2070mm |
3070 x 1160 x 1765mm |
75kg |
9193w |
9202w |
9211w |
| 10 |
2300mm |
3300 x 1160 x 1900mm |
87kg |
9194w |
9203w |
9212w |
| OPTIONAL EXTRA |
| Description |
Type |
| Hook-on Container |
9185w |
