Description
Shifting Industrial Skates are designed for moving heavy objects, such as factory machinery, power generators, large steel constructions etc.
The load can be raised using a jack (hydraulic or ratchet). Some lighter loads can be lifted with a crowbar.
Steerable skates are maintenance free with sealed bearings.
The industrial skates are fitted with handles for ease of carrying and positioning.
The skate platforms have rubber surfaces for protection and stability of load.
The steerable skates are usually used with adjustable skate pairs to form a triangular or rectangular skate set.
Specification
.tg {border-collapse:collapse;border-spacing:0;}
.tg td{font-family:Arial, sans-serif;font-size:14px;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg th{font-family:Arial, sans-serif;font-size:14px;font-weight:normal;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg .tg-baqh{text-align:center;vertical-align:top}
.tg .tg-9hbo{font-weight:bold;vertical-align:top}
.tg .tg-amwm{font-weight:bold;text-align:center;vertical-align:top}
| Type |
3498w |
3499w |
3500w |
| Capacity |
3000kg |
6000kg |
12000kg |
| No of roller |
4 |
8 |
8 |
| Roller size |
85mm dia x 90mm |
85mm dia x 90mm |
83mm dia x 85mm |
| Drawbar |
Handle |
Handle & 52mm dia towing eye |
Handle & 52mm dia towing eye |
| Overall L x W x H |
310 x 255 x 105mm |
630 x 400 x 115mm |
630 x 400 x 115mm |
| Roller material |
Nylon |
Nylon |
Steel |
| Weight |
15kg |
50kg |
66kg |
