Description
> Economic Lift Table developed for industrial environments
> Ideal for manoeuvring, positioning or assembling parts.
> High quality positive feel hydraulics
> Fitted with 2 maintenance stops
> Foot operated pump lift with controllable hand operated lowering
> Overload relief & by-pass valves
> Fully mobile on 2 fixed & 2 swivel guarded castors
> Fully compliant to BSEN1570
Please note: colour/appearance may differ from images shown
Specification
.tg {border-collapse:collapse;border-spacing:0;}
.tg td{font-family:Arial, sans-serif;font-size:14px;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg th{font-family:Arial, sans-serif;font-size:14px;font-weight:normal;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg .tg-baqh{text-align:center;vertical-align:top}
.tg .tg-9hbo{font-weight:bold;vertical-align:top}
.tg .tg-amwm{font-weight:bold;text-align:center;vertical-align:top}
| Type
| Capacity
| Min table
height
| Max table height
| Table size
W x L
| Handle
Height
| Wheel dia
| Strokes to
full height
| Weight
|
| 2526w |
150kg |
220mm |
720mm |
450 x 700mm |
950mm |
100mm |
28 |
46kg |
| 2527w |
300kg |
340mm |
915mm |
500 x 855mm |
970mm |
125mm |
27 |
75kg |
| 2528w |
500kg |
285mm |
880mm |
500 x 850mm |
990mm |
127mm |
27 |
81kg |
| 3494w |
1500kg |
420mm |
1010mm |
610 x 1220mm |
970mm |
150mm |
52 |
142kg |
